High Efficiency Hydraulic Scrap Metal Plate High Speed Fast Double-edged Shearing Machine

Q08 series Fast scrap shear machine Details This machine is used for cold shearing of various sectional shape scrap metal and cutting off various specified lengths of steel in rolling mill. Q08 series of scrap metal shear machine is our factory introduced world most advanced models in 2008.This...

Send Inquiry

Chat Now

Q08 series Fast scrap shear machine

Details

This machine is used for cold shearing of various sectional shape scrap metal and cutting off various specified lengths of steel in rolling mill.

Q08 series of scrap metal shear machine is our factory introduced world most advanced models in 2008.This machine not only maintain all technical parameters of the old modelsits actual shear force increase 10%.

Features

Rapid system

Hydraulic differential growth of domestic initiation systems using the fast loop without increasing the motor power and pump displacement shear rate increased by 6 times per minute to 12 times per minute (shear mouth biggest) more quickly more energy saving.

Unibody construction

New design one-piece casting steel fuselage exempt from tedious installation more durable

A bigger mouth

We increased the shear mouth enlarged the scope of scrap shear shape more complex mixed structure can be cut at a time.

Special material seal

Resistance to high temperature high pressure service life greatly ascend

Type	shearing speed (times/min)	Motor power	max shearing force (KN)	max shear opening	blade length
Q08-40	14~25	5.5KW	400	220	400
Q08-63	14~25	7.5KW	630	280	600
Q08-80	14~25	11KW	800	320	600
Q08-100	14~25	15KW	1000	320	600
Q08-125	12~25	15KW	1250	320	600
Q08-160	11~25	15KW	1603	320	600
Q08-200	10~20	18.5KW	2000	400	800
Q08-250	10~20	22KW	2500	400	800
Q08-315	10~20	30KW	3150	490	1000
Q08-400	10~20	37KW	4000	560	1200

Welcome to buy the high efficiency hydraulic scrap metal plate high speed fast double-edged shearing machine made in China from our factory. As one of the leading such manufacturers and suppliers in China, we will offer you now only the best quality products but also excellent service.
