High Pressure Hydraulic Scrap Metal Plate guillotine Shearing Machine

Introduction
Hydraulic Scrap Metal Plate Guillotine Shearing Machine is a type of equipment used for cutting and processing scrap metal plates. It is widely used in the metal recycling industry and can be used to process various types of metal plates, such as steel plates, aluminum plates, copper plates, and so on.Q15 series of square sheet are applied to cut sheet metals substituting flame cutting.Cost of production reduced.

Type	Maximum shear force	Blade length	Every minute Shearing	Maximum shear blade open	Maximum shear plate thickness	Power (kw)
Type	（ KN ）	(mm)	(times/min)	(mm)	(mm)	(kw)
Q15-1200	1200	600	6~8	130	20 *600	15
Q15-1200	1200	1200			20*1200	15
Q15-1600	1600	600/800			25*600	18.5
Q15-1600	1600	1200			25*1200	18.5
Q15-2000	2000	600/800			28*500	22
Q15-2000	2000	1200			28*1200	22
Q15-2500	2500	600/800			30*500	30
Q15-2500	2500	1600			30*1600	30
Q15-3150	3150	800			35*800	37
Q15-5000	5000	800			40*800	44
NOTE:1. Bigger shear blade opening, less cutting number per minute. 2.The material of tensile strength Qb>450Mpa is not suitable for this shear.

Working principle

The working principle of the Hydraulic Scrap metal guillotine cutting machine is as follows:
1. The scrap metal plate is placed on the workbench of the machine.
2. The operator adjusts the blade gap according to the thickness of the metal plate.
3. The operator controls the hydraulic system to drive the blade to move down and cut the metal plate.
4. The cut metal plate falls onto the conveyor belt and is transported to the next process.

Product Feature

The Hydraulic Scrap Metal Plate Guillotine Shearing Machine has the following features:
1. High efficiency: The machine can quickly and efficiently cut and process scrap metal plates, which improves processing efficiency and reduces labor costs.
2. High precision: The machine can accurately cut metal plates of different thicknesses, which ensures the quality of the cutting.

3. Easy operation: The machine is equipped with a user-friendly control system, which makes it easy for the operator to control the machine and adjust the blade gap.
4. Safety: The machine is equipped with safety devices, such as emergency stop buttons and safety covers, to ensure the safety of the operator during operation.
5. Low noise: The machine is equipped with noise reduction devices, which reduces the noise generated during operation and provides a better working environment.
In summary, the Hydraulic Scrap Metal Plate Guillotine Shearing Machine is an efficient and precise cutting and processing equipment used in the metal recycling industry. It has the advantages of high efficiency, high precision, easy operation, safety, and low noise, which makes it an ideal choice for metal plate cutting and processing.
